HL-CK-420 full automatic Paper punching machine is an equipment specialized in paperboard punching, mainly used for binding hole punching in the calendar, notebook, exercise book, gray cardboard, PP board, etc.
This machine can feed papers automatically by step drive and can adjust paper thickness. After the suction nozzle feed the machine on the conveyor belt, the paper will be carried into the punching dies area. After it is trimmed tidily, it will start to punch. Then the punched paper is delivery to the stacker. The paper sizes and page margins can be adjusted. We can punch various holes by replacing different shapes punching die.
automatic Paper punching machine
Detailed Data:
| Maximum Size(Width x Length) | 420 x 420mm |
| Minimum Size(Width x Length) | 170 x 150mm |
| Maximum Punching Thickness | 2mm |
| Maximum Stack Thickness | 600mm |
| Paper Specification | 60-200g/ m2 |
| Maximum Working Speed | 7200Times/h |
| Collection Style | Lift Style and Conveyer Belt Style for Choices |
| Power | AC380V/3ph/50Hz/3kw |
| Machine Dimension(Length x Width x Hight) | 2200 x 1000 x 1300mm |
| Machine Weight | 800kg |
| Air Compressor(Excluded) | 0.37kw |
| Air Compressed | 4-6Bar |
Punching dies
Video of HL-CK-420 full automatic Paper punching machine
